News

29.07.2015
US Premiere of new ECAT ADMM 4 HS800

Hard- and software to measure data rates up to 800 kHz per channel

US premiere of CSM Products’ new analog measurement module ECAT ADMM 4 HS800 and the new data acquisition software CSMmeasure at the Automotive Testing Expo North America 2015.


Data rates up to 800 kHz per channel for fast mobile measurements: For the first time CSM Products, Inc. presents the new EtherCAT®-based analog measurement module ECAT ADMM 4 HighSpeed800 and the new easy-to-use data acquisition software CSMmeasure in the USA at the Automotive Testing Expo North America. Visit us from 20 to 22 October 2015 in Novi, MI, Suburban Collection Showplace, booth 5010. Experience the new ECAT ADMM 4 HS800, the new CSMmeasure and our other trade fair highlights: Robust EtherCAT®- and CAN-based measurement modules and data loggers for automotive measurement applications.


Software CSMmeasure: Just a few clicks from configuration to visualization

CSMmeasure is the new easy-to-use data acquisition software for all CSM measurement modules. With just a few clicks the software leads the user from configuration to visualization of the measurement results. The software supports data rates up to 800 kHz per channel. Additionally, CSMmeasure records video and GPS data. Due to the new software, CSM Products, Inc. is now able to offer all-in-one solutions for complex measurement tasks from one source.


ECAT ADMM 4 HS800: Fast mobile measuring hardware for precise acquisition of signal curves

Data rates up to 800 kHz per channel for fast mobile measurements: This is what you get from the new EtherCAT®-based analog measurement module ECAT ADMM 4 HS800. With 4 synchronous inputs the module is ideal for precise dynamic acquisition of signal curves from combustion engines, electric motors and electric auxiliary systems. Thanks to the high protection class IP67 and the operating temperature range from -40°C to +125°C the module can be mounted directly in engine compartments. This reduces noise to an absolute minimum.


Electric Mobility: CSM Products, Inc. presents high voltage measurement modules

Precise A/D and temperature measurements at high-voltage (HV) components: CSM’s CAN-based high-voltage measurement modules allows safe A/D- and temperature measurement at HV components in electric and hybrid vehicles. Thanks to the reinforced insulation up to 800 V and the multi-level safety concept, tested and approved by an accredited test lab according to EN 61010 safety standard, these modules guarantee safe measurement under harsh environmental conditions. At the Automotive Testing Expo North America, CSM Products, Inc. presents two device types: MiniModules for mobile measuring and 19'' slide-in modules for test bench applications.


CAN-based measurement: Optimized MiniModules for mobile measurements

CSM Products, Inc. presents robust, compact and highly accurate CAN MiniModules for distributed measurements on driving test ranges, road tests and in test benches. The MiniModules provide efficient measurement of temperature (thermo, RTD), voltage (pressure, acceleration etc.), mechanical strain (strain gauges etc.) and RPM (PWM, event counting etc.). Thanks to the high protection class IP67 and the operating temperature range from -40°C to +125°C the MiniModules can be mounted directly in engine compartments. This reduces noise to an absolute minimum.


EtherCAT® MiniModules for fast synchronized mobile measurements

CSM’s EtherCAT® MiniModules combine the advantages of Ethernet technology and the EtherCAT® protocol to be used in the fields of automotive testing. The modules are ideal for distributed synchronized measurement with high data rates and many channels. The MiniModules offer high-speed measurement with data rates up to 800 kHz per channel and module synchronization better 1 µs.

To integrate high-speed measurement needs into a complex measurement system containing numerous conventional CAN-based devices, CSM's XCP-Gateway plays a decisive role. It merges the data of CSM EtherCAT® MiniModules with data of CSM CAN-devices into XCP on Ethernet frames, synchronizes and aligns the sampling points and provides all data according to the XCP on Ethernet standard.



Download Press text:

CSM_PR_Preview-Automotive-Testing-Expo-North-America.zip



Download images:

CSM's EtherCAT® module ECAT ADMM 4 HS800

CSM's EtherCAT® module ECAT ADMM 4 HS800

CSM's CAN-based HighVoltage measurement modules

CSM's CAN-based HighVoltage measurement modules

CSM's CAN-based measurement modules

CSM's CAN-based measurement modules

CSM's XCP-Gateway

CSM's XCP-Gateway

17.07.2015
Release CSM INCA AddOn V2.44

CSM INCA AddOn V2.44 is now available. For customers with an INCA AddOn maintenance contract, the new software package is made available to the contact persons responsible via download link.

New features:

►  Support of the modules ADMM 4 classic HS (hardware revision E500) and ADMM 4 pro HS (hardware revision E400).
►  Integration of ECM modules (LambdaCANc, NOxCANx) in DBC export.

Improvements for INCA 6.x and 7.x:
►  Improved operational stability during voltage drops at ETAS CAN adapters.
►  Improved initialisation of LambdaCANc if DashCANc is connected.

Apart from these major changes, further improvements and corrections were implemented. Please refer to the release notes of the software package for details.

If you have further wishes, suggestions or requests please do not hesitate to contact your account manager or our Support-Team support@csm.de.





25.06.2015
CSM xx-Scan Config V7.9.0 Release

The new version of xx-Scan Config is now available. You can download the configuration software for all CSM measurement modules in our download section.

New Features in V7.9.0:

  • Additional functions in ADMM 8 pro and ADMM 8 pro2: As sensor characteristic tables are now supported, non-linear input signals can already be linearized while the measurement is running.
  • ADMM 8 pro supports an adjustable history depth when an average value is output. The average value is thus independent of the module’s sampling rate.
  • This release includes new firmware versions for the modules THMM 16 classic, THMM 16 pro, ADMM 8 pro and ADMM 8 pro2. New functions are only available if the new firmware has been installed. The firmware is included in the scope of delivery.


Apart from these major changes, further improvements were implemented. Please refer to the release notes of the software package for details.


Please note:
xx-Scan Config support of Windows XP/Vista will end in December 2015. As from 2016 new versions of xx-Scan Config won’t work under Windows XP/Vista.

Our recommendation:
Windows XP/Vista users who want to continue to use xx-Scan Config in 2016 need to update the operating system to a more recent version, at least Windows 7 or higher, by the end of December 2015


If you have further wishes, suggestions or requests please do not hesitate to contact your account manager or our Support-Team support@csm.de.

03.06.2015
Sampling rates up to 800 kSa/s

Premiere of CSM’s ECAT ADMM 4 HighSpeed measurement module at the Automotive Testing Expo Europe


Achieving higher sampling rates for precise data acquisition in order to optimize tomorrow's combustion engines and its auxiliary systems as well as electrified traction systems belong to the key issues the world of automotive measurement technology is dealing with. With the High Speed A/D measurement module ECAT ADMM 4 HS, CSM provides an appropriate answer, combining very high sampling rates with a user-friendly connection scheme and time-synchronous data acquisition using EtherCAT® as data interface.


Precise dynamic acquisition of transient effects through sampling rates up to 800 kSa/s

The large measurement range of up to 90 V in combination with a maximum sampling rate of up to 800 kSamples/sec per channel allows the precise dynamic signal acquisition and analysis of transient effects while switching high current actuators like those used in an electrical steering. Also, as a result of the synchronous sampling of all channels, the phase relationship between voltage and current on complex loads can be measured at high resolution.


The combination of very high measurement speed and integrated sensor excitation makes ECAT ADMM 4 HS a perfect choice for all fields of application where fast measurement processes and a high degree of operating reliability are essential, e.g. for measurement of displacement, combustion chamber pressure, vibration, acceleration etc. in combustion engines.


Easy configuration with CSM’s xx-Scan Config Software

All settings can be easily controlled by CSM’s configuration tool xx Scan Config, supporting the entire portfolio of CSM measurement modules. Among other things, xx-Scan Config also processes the data from Sensores with TEDS abilities, which can be queried via the module’s built-in TEDS interface (compliant with IEEE 1451.4).


EtherCAT® enables precise and synchronous measuring

Like all other CSM ECAT measurement modules, ECAT ADMM 4 HS communicates via a standard-compliant EtherCAT® interface. It can be operated on acquisition systems providing suitable EtherCAT® master software (e.g. MLab®) and appropriate configuration options. The measurement data rate, however, is limited to max. 10 kHz.


For applications with higher requirements regarding measurement data rate and synchronization, e.g. for multi-channel data acquisition from numerous devices of a measurement chain, CSM’s XCP-Gateway provides the means to convert the data from EtherCAT® to XCP-on-Ethernet for further processing and visualization in a measurement and calibration software, like e.g. CANape® and INCA®. Data processing with sampling rates up to 800kSamples/sec can currently only be realized with XCP-Gateway in combination with CSM DAQ tool or Vector CANape®.





Download Pictures:

ECAT ADMM 4 HS

ARTxxxxxxx EtherCAT ADMM HS Preview PA-Thumb

XCP-Gateway

ART1120202 XCP-Gateway PA-Thumb



Download Press text:

CSM_PR_ECAT ADMM 4 HS-EN.zip
